Fuse 48 - A/C - amps?

Trying to troubleshoot a parasitic drain. I bought a Amp Hound 2 and checked all fuses. One fuse, with power off and car sleep, is pulling .07 amps. Itís fuse 48, which the panel says is A/C.

What would cause that draw on that circuit with the car off? Anything I should look at or trace from that? Or am I chasing a non issue?
Reply With Quote

Sponsored Links

  #2
Old 04-21-2021, 09:10 PM
Zulu95's Avatar
Member

Join Date: Mar 2005
Location: Show Me
Posts: 2,593
Zulu95 is on a distinguished road
25 Amps.







__________________
Sent via Telegraph Wires using my Morse Key.
2015 X5
xDrive35i MSport
2013 X5 xDrive35i

Last edited by Zulu95; 04-21-2021 at 09:19 PM.
Reply With Quote
  #3
Old 04-21-2021, 09:17 PM
Overboost's Avatar
//Binary is in my DNA

Join Date: Apr 2006
Location: Huntersville, NC
Posts: 3,201
Overboost is on a distinguished road
Nice to see you back visiting us over here @zulu95
Reply With Quote
  #4
Old 04-21-2021, 09:21 PM
Zulu95's Avatar
Member

Join Date: Mar 2005
Location: Show Me
Posts: 2,593
Zulu95 is on a distinguished road
Cannot stay away. Still miss my old girl even though the E70 and F15 are really nice. If I tripped over an E53 somewhat like the one I sold and it was the really right money it could follow me home.
__________________
Sent via Telegraph Wires using my Morse Key.
2015 X5
xDrive35i MSport
2013 X5 xDrive35i
Reply With Quote
  #5
Old 04-21-2021, 09:25 PM
Overboost's Avatar
//Binary is in my DNA

Join Date: Apr 2006
Location: Huntersville, NC
Posts: 3,201
Overboost is on a distinguished road
Your contributions over the years were much appreciated on our sub-forum. Get another E53 for a daily and kick it with us again.
Reply With Quote
  #6
Old 04-21-2021, 09:28 PM
Member

Join Date: Jan 2019
Location: Virginia
Posts: 120
Siggy is on a distinguished road
Not sure I understand the 25 amp answer. I’m looking for the amp value on fuse 48 with the car off. Should be zero, right? Not .07 amps?
Reply With Quote
  #7
Old 04-21-2021, 09:38 PM
Zulu95's Avatar
Member

Join Date: Mar 2005
Location: Show Me
Posts: 2,593
Zulu95 is on a distinguished road
Could be 0.7A until the system fully powers down and goes to sleep. 700mA could keep the car awake. You'll need to pull connectors in the AC circuit until it disappears. Could be the head unit, the FSR, the little fan in the dash or anything else in there.
__________________
Sent via Telegraph Wires using my Morse Key.
2015 X5
xDrive35i MSport
2013 X5 xDrive35i
Reply With Quote
  #8
Old 04-21-2021, 09:43 PM
Zulu95's Avatar
Member

Join Date: Mar 2005
Location: Show Me
Posts: 2,593
Zulu95 is on a distinguished road
Quote:
Originally Posted by Overboost View Post
Your contributions over the years were much appreciated on our sub-forum. Get another E53 for a daily and kick it with us again.
Thank you.
At my stage in life you know to never say never. The right car, the right price and anything can happen.
__________________
Sent via Telegraph Wires using my Morse Key.
2015 X5
xDrive35i MSport
2013 X5 xDrive35i
Reply With Quote
  #9
Old 04-22-2021, 04:47 AM
wpoll's Avatar
Member

Join Date: Sep 2015
Location: South Island, New Zealand
Posts: 3,923
wpoll will become famous soon enough
70mA (not 700mA) is pretty low but it seems a bit more than is normal (~18mA).

The fan speed control component (output stage, N2 - a.k.a. the final stage resistor or "hedgehog") is a likley problem. It has it's own supply (via fuse 64) but has signals from the IHKA module (fed from fuse 48).
__________________
Wayne
2005 BMW X5 3.0d (b 02/05)
2001 BMW F650GS Dakar (b 06/01)
Reply With Quote
  #10
Old 04-22-2021, 08:33 AM
Member

Join Date: Jan 2013
Location: Finland
Posts: 837
Clavurion is on a distinguished road
If the vehicle really is in sleep mode (for example gear selector position light is out) the problem must be IHKA itself as it should not direct any current to components.
__________________
E39 530dA -02 M-Sport Messing metallic
E53 X5 3.0dA -06 Sport Stratus grey
Reply With Quote
