What parts am I missing?

I have searched and researched my head off, trying to wrap my brain around the thousand and one options for the E53.
I installed a Motorola bluetooth in my Jaguar, and may do the same in the X5, or I might go BMW plug and play. But first, what are all these pieces I have?
FYI, it's a 2001. X5, 4.4, build date 06/01, Canadian model, with nav and DSP.

Thanks in advance, and a Merry Christmas to all, from myself, Rob, and my family.

First, the armrest.



An antenna of some sort, with 3 coax cables:



Assorted plugs by the Nav system:


Something, maybe an amp?



And a couple unused plugs:







Reply With Quote

Sponsored Links

  #2
Old 12-20-2011, 06:57 PM
Member

Join Date: Jan 2011
Location: Langley BC
Posts: 12
avt007 is on a distinguished road
The antenna found is a "diversity" antenna seen here- http://wds.spaghetticoder.org/zi_images/G_120016.png

What is it used for?
Reply With Quote
  #3
Old 12-21-2011, 07:20 AM
Member

Join Date: Jun 2006
Location: UK
Posts: 698
big bob is on a distinguished road
Div amp is for the Radio.

I see an SES jumper plug, and a 25 pin DB25. You have what looks like FME cables running for the Bluetooth RF from console to trunk, rather than the later FAKRA


You need a DB25 to 54 pin adaptor, a Bluetooth antenna, a ULF/TCU, and a ~25cm FAKRA cable and mount the antenna above the nav drive.

http://www.bimmernav.com/BMW_X5_Blue...tructions.html

Last edited by big bob; 12-21-2011 at 07:28 AM.
Reply With Quote
  #4
Old 12-22-2011, 03:28 PM
Member

Join Date: Jan 2011
Location: Langley BC
Posts: 12
avt007 is on a distinguished road
OK thanks Bob. I was foolishly hoping that I could buy one component and be done with it.
I may do some more digging and install the same Bluetooth that my Jag has. If so I'll post how it all works out in case someone else wants to go that route.

Rob
Reply With Quote
  #5
Old 12-22-2011, 05:35 PM
UCrewX5's Avatar
co-founder

Join Date: Mar 2005
Location: Hockeytown, USA
Posts: 9,737
UCrewX5 has disabled reputation
here is how I retrofitted BT into my 2001 X5 - http://www.xoutpost.com/articles/all...01-bmw-x5.html
