  #11
Old 08-17-2012, 10:39 AM
epdarks's Avatar
Member

Join Date: Jul 2012
Location: Mpls, MN
Posts: 883
epdarks is on a distinguished road
Yes, thanks for the write-up. Looking forward to seeing the finished product.
__________________
2002 X5 4.6is - Titanium Silver / Black Alcantara - Dinan Stage 2 - Bilstein/Eibach - Brembo BBK ----SOLD---
1993 318i - Brilliantrot / Tan - bone stock daily driver
Reply With Quote

Sponsored Links

  #12
Old 08-19-2012, 12:09 AM
X5SND's Avatar
Member

Join Date: Apr 2008
Location: Winnipeg, Mb
Posts: 1,908
X5SND is on a distinguished road
As promised....

A few things to get out of the way Before we dig into this bit.
1) As it was mentioned previously, If you plan on recovering the headliner yourself, GET MATERIAL THAT HAS A FAIR AMOUNT OF STRETCH.
2) To keep the "luxury" feel, get a material that is laminated to at least 1/8" of foam. Otherwise you headliner will literally be a piece of fiberglass wrapped in material (and feel like it to).

Now for the fun bit....things you need:
Razor blade(s)
3 yards of covering material, 4 if you plan on doing the sunroof cover
Material adhesive (3m is bout the standard issue, best thing to do for products available in your are is head to a shop supply house and talk to the guys there, aka NAPA/CMAX)
Some sort of rotary disc grinder with a scotchbrite pad

The Game Plan:
  • Rip the old material off the headliner
  • Clean the headliner board down to the fiberglass
  • Glue new material down
  • Cut holes for Handles, hooks, Visors, etc.
Getting the old material off is easy as pie, just lift a corner and go to town. If you're lucky, the old foam underneath will come off with it. (Sadly I wasn't)
Starting the removal process...


Next comes the tedious task of cleaning all the old foam off. Personally I don't know how people say to just scrape it off, mine was in no way ready to give up adhesion to the headliner backing. Using a mini air grinder and scotchbrite pads, i was able to easily remove the remaining foam and clean the fiberglass. Make sure you get into all the valleys and corners. The more OCD you are at this stage the less headaches you'll have later.

Once its done, should look something like this......


At this stage I got lazy and decided to take my headliner to a local guy who does interior work for alot of the street rods and custom cars around here. I watched as he recovered the headliner.....things to note if you do it yourself. The level of difficulty is highly dependent on the amount of stretch your material has. MORE STRETCH = LESS DIFFICULT!!
  • Lay Out the material over top first, to get a sense of what it will be like for working the corners and curves BEFORE you spray the glue.
  • Start in the center and work towards the sides. You can work a section at a time, but be warned, this way you are more likely to get glue where you don't want it (on the good side of the material)
  • MORE IS NOT BETTER. Using too much adhesive will cause it to bleed through the material, ruining this whole exercise. My recommendation if you're using aerosol cans: cut a small piece of fabric and spray some glue on the foam so A) You have an idea of how it comes out of the can, and B) you establish a threshold for amount of adhesive it can withstand before it starts to bleed through.
  • When you get to the sunroof, do it last. Cut out the center leaving about 2" from the edge. Then cut the corners at the beginning and end of the curve (essentially leaving you with 4 straight pcs. along the sides and curved pcs. Glue the straight pieces first, then do the corners. You'll have to make relief cuts in the corners so you don't get pulls or wrinkles (how many depends on the material).
  • When you get to the edge of the headliner, you only need to leave enough to fold over about an inch.
This is what the material I was using looks like:


Once you work the fabric down, and its dry you need to cut the holes for the sun visors, lights, hooks, handles and consoles. DONT FORGET TO PUNCH THE HOLES FOR SUN VISOR CATCHES. (I discovered that one the hard way). To make things simple, the cuts are as follows:
Vanity Lights & Grab Handles: Just cut an X from the back making sure to go just up to the corner.
Sun Visor Mounts & Accessory Hooks: Cut a hole in the center leaving ~1/8" around the edges.
Consoles: Cut it flush with the edge.

Like so:


Ready to go back in:



Once you have all the holes trimmed nicely its time to put the darn thing back in, and enjoy a cold one!
__________________
2004 X5 3.0i

Mod list: Currently Longer than the maximum allowed characters that can be typed here...


Last edited by X5SND; 08-19-2012 at 12:25 AM.
Reply With Quote
  #13
Old 08-19-2012, 12:17 AM
X5SND's Avatar
Member

Join Date: Apr 2008
Location: Winnipeg, Mb
Posts: 1,908
X5SND is on a distinguished road
Some Pics of the finished product.....

__________________
2004 X5 3.0i

Mod list: Currently Longer than the maximum allowed characters that can be typed here...

Reply With Quote
  #14
Old 08-19-2012, 08:05 PM
valex9499's Avatar
Member

Join Date: Jun 2009
Location: coral springs Fl
Posts: 105
valex9499 is on a distinguished road
Good write up! I wish I had one when I did mine. Just to point out to anyone who is planning on doing this, don't buy suede from joann fabrics. It won't stretch and will not stick good.
Reply With Quote
  #15
Old 08-19-2012, 09:56 PM
papasmurf's Avatar
Member

Join Date: Nov 2009
Location: New Jersey
Posts: 465
papasmurf is on a distinguished road
Why didn't you do beige material or at least switch to all black plastic?
__________________
Reply With Quote
  #16
Old 08-20-2012, 11:58 AM
X5SND's Avatar
Member

Join Date: Apr 2008
Location: Winnipeg, Mb
Posts: 1,908
X5SND is on a distinguished road
Quote:
Originally Posted by papasmurf View Post
Why didn't you do beige material or at least switch to all black plastic?
I wanted to go for something a bit different, hence the 2-tone. I entertained the idea of doing black pillars, but when the headliner was in and all my pillars were still off, with my truck being black I could see basically what it would have looked like.....And it looked odd with everything from the window line up black and everything below beige. I will be recovering all the pillars and sunroof cover in beige suede though in the weeks to come!
__________________
2004 X5 3.0i

Mod list: Currently Longer than the maximum allowed characters that can be typed here...

Reply With Quote
  #17
Old 10-11-2012, 07:41 AM
ake53's Avatar
Member

Join Date: Jun 2012
Location: Springfield MA
Posts: 651
ake53 is on a distinguished road
Quote:
Originally Posted by X5SND View Post
I wanted to go for something a bit different, hence the 2-tone. I entertained the idea of doing black pillars, but when the headliner was in and all my pillars were still off, with my truck being black I could see basically what it would have looked like.....And it looked odd with everything from the window line up black and everything below beige. I will be recovering all the pillars and sunroof cover in beige suede though in the weeks to come!
where did you get the suede? you have a link?
__________________
2009 BMW E60 LCI 528Xi


SOLD
2002 BMW X5 3.0i E53



Reply With Quote
  #18
Old 10-11-2012, 12:02 PM
X5SND's Avatar
Member

Join Date: Apr 2008
Location: Winnipeg, Mb
Posts: 1,908
X5SND is on a distinguished road
Got mine locally. Google could probably kick over some good results though!
__________________
2004 X5 3.0i

Mod list: Currently Longer than the maximum allowed characters that can be typed here...

Reply With Quote
  #19
Old 10-12-2012, 01:19 AM
Barney Rubble's Avatar
Member

Join Date: Mar 2008
Location: Sunshine Coast Australia
Posts: 95
Barney Rubble is on a distinguished road
Nice write up, looks good. Motivation!
Reply With Quote
  #20
Old 10-12-2012, 08:03 AM
ake53's Avatar
Member

Join Date: Jun 2012
Location: Springfield MA
Posts: 651
ake53 is on a distinguished road
it looks really nice. 2 tone perfect. makes me not hate the beige interior as much now... ahh i see theres a display in the sun glass holder compartment on the roof... that must be your air suspension display? also really like the rims... makes me less hate the 3.0 weaker look.
__________________
2009 BMW E60 LCI 528Xi


SOLD
2002 BMW X5 3.0i E53



Reply With Quote
