  #21
Old 10-12-2012, 11:31 AM
X5SND's Avatar
Member

Join Date: Apr 2008
Location: Winnipeg, Mb
Posts: 1,908
X5SND is on a distinguished road
Quote:
Originally Posted by alex77ae View Post
it looks really nice. 2 tone perfect. makes me not hate the beige interior as much now... ahh i see theres a display in the sun glass holder compartment on the roof... that must be your air suspension display? also really like the rims... makes me less hate the 3.0 weaker look.
Thanks!
That's is my air display up top. I should really get on finishing off the sides one of these days...
As for the overall look, my efforts went to give it a more aggressive road presence while still differentiating it from a 4.8, both inside and out.
__________________
2004 X5 3.0i

Mod list: Currently Longer than the maximum allowed characters that can be typed here...

Reply With Quote

Sponsored Links

  #22
Old 06-15-2013, 10:48 PM
Member

Join Date: Feb 2011
Location: Calgary, Canada
Posts: 1,717
Clockwork is on a distinguished road
X5SND, thanks for the write up. I need to remove my headliner to access my pano roof to check why its rattling. Appreciate the pics/description. I'm going to assume its 99% as same for my x5, just more screws/clips around the pano, and a few other odd differences. looking forward to getting to the bottom of this rattle.
__________________
I swear, my cars are like a girlfriend.
Sometimes its a rough ride, sometimes its smooth motorin'.
Sometimes she doesnt like how i treat her and sometimes i dont like how she behaves.
BUT at the end of the day, she loves it when I am inside her.

_______________________
'91 850i
'05 X5 4.4i
Reply With Quote
  #23
Old 06-16-2013, 12:00 AM
X5SND's Avatar
Member

Join Date: Apr 2008
Location: Winnipeg, Mb
Posts: 1,908
X5SND is on a distinguished road
You're welcome, Glad it can be of some use! Hopefully someone with a pano-roof who has had to remove the headliner will be able to fill in the gaps.
__________________
2004 X5 3.0i

Mod list: Currently Longer than the maximum allowed characters that can be typed here...

Reply With Quote
  #24
Old 06-17-2013, 10:43 AM
Member

Join Date: Feb 2011
Location: Calgary, Canada
Posts: 1,717
Clockwork is on a distinguished road
X5SND, the removal sets for the Pano roof are exact same as your write up, just a larger hole for sunroof and therefore more "snaps" to unclip/clip. Easy to do, once all the accessories are finally off the roof, holy cow.
__________________
I swear, my cars are like a girlfriend.
Sometimes its a rough ride, sometimes its smooth motorin'.
Sometimes she doesnt like how i treat her and sometimes i dont like how she behaves.
BUT at the end of the day, she loves it when I am inside her.

_______________________
'91 850i
'05 X5 4.4i
Reply With Quote
  #25
Old 06-17-2013, 08:13 PM
X5SND's Avatar
Member

Join Date: Apr 2008
Location: Winnipeg, Mb
Posts: 1,908
X5SND is on a distinguished road
Updated the guide to include the new info, and changed the first post to hopefully make it easier for other members to find! Thanks again for the additional info!
__________________
2004 X5 3.0i

Mod list: Currently Longer than the maximum allowed characters that can be typed here...

Reply With Quote
  #26
Old 06-18-2013, 08:24 AM
Member

Join Date: Feb 2011
Location: Calgary, Canada
Posts: 1,717
Clockwork is on a distinguished road
you're most welcomed sir. I'm sure this will help others.
__________________
I swear, my cars are like a girlfriend.
Sometimes its a rough ride, sometimes its smooth motorin'.
Sometimes she doesnt like how i treat her and sometimes i dont like how she behaves.
BUT at the end of the day, she loves it when I am inside her.

_______________________
'91 850i
'05 X5 4.4i
Reply With Quote
  #27
Old 09-03-2014, 12:52 PM
Member

Join Date: Jul 2013
Location: Ohio
Posts: 213
mcurcio1989 is on a distinguished road
Clockwork - would you mind giving some additional detail on the clips for the pano roof? I looked up the number but I am not getting a picture. I'd like to know how they are designed to come free and how likely they are to self destruct in trying to get them free. Also I have no idea where those for torque screws are. Are they hidden by something or require the headliner to be pulled a way a bit or do I just need to look better?

Also can this be done with the pano closed?? That is probably the biggest question.

The rest of the process sounds pretty straight forward.

I'm kind of bored waiting for my pano repair kits to come some I'm trying to make sure I'm familiar with this process beforehand
__________________
2004 e53 m54 with 6spd manual
Reply With Quote
  #28
Old 09-17-2015, 09:02 PM
Member

Join Date: Jun 2015
Location: Southlake, Texas
Posts: 2,072
X53Jay4.8is is on a distinguished road
Quote:
Originally Posted by X5SND View Post
As promised....

A few things to get out of the way Before we dig into this bit.
1) As it was mentioned previously, If you plan on recovering the headliner yourself, GET MATERIAL THAT HAS A FAIR AMOUNT OF STRETCH.
2) To keep the "luxury" feel, get a material that is laminated to at least 1/8" of foam. Otherwise you headliner will literally be a piece of fiberglass wrapped in material (and feel like it to).

Now for the fun bit....things you need:
Razor blade(s)
3 yards of covering material, 4 if you plan on doing the sunroof cover
Material adhesive (3m is bout the standard issue, best thing to do for products available in your are is head to a shop supply house and talk to the guys there, aka NAPA/CMAX)
Some sort of rotary disc grinder with a scotchbrite pad

The Game Plan:
  • Rip the old material off the headliner
  • Clean the headliner board down to the fiberglass
  • Glue new material down
  • Cut holes for Handles, hooks, Visors, etc.
Getting the old material off is easy as pie, just lift a corner and go to town. If you're lucky, the old foam underneath will come off with it. (Sadly I wasn't)
Starting the removal process...


Next comes the tedious task of cleaning all the old foam off. Personally I don't know how people say to just scrape it off, mine was in no way ready to give up adhesion to the headliner backing. Using a mini air grinder and scotchbrite pads, i was able to easily remove the remaining foam and clean the fiberglass. Make sure you get into all the valleys and corners. The more OCD you are at this stage the less headaches you'll have later.

Once its done, should look something like this......


At this stage I got lazy and decided to take my headliner to a local guy who does interior work for alot of the street rods and custom cars around here. I watched as he recovered the headliner.....things to note if you do it yourself. The level of difficulty is highly dependent on the amount of stretch your material has. MORE STRETCH = LESS DIFFICULT!!
  • Lay Out the material over top first, to get a sense of what it will be like for working the corners and curves BEFORE you spray the glue.
  • Start in the center and work towards the sides. You can work a section at a time, but be warned, this way you are more likely to get glue where you don't want it (on the good side of the material)
  • MORE IS NOT BETTER. Using too much adhesive will cause it to bleed through the material, ruining this whole exercise. My recommendation if you're using aerosol cans: cut a small piece of fabric and spray some glue on the foam so A) You have an idea of how it comes out of the can, and B) you establish a threshold for amount of adhesive it can withstand before it starts to bleed through.
  • When you get to the sunroof, do it last. Cut out the center leaving about 2" from the edge. Then cut the corners at the beginning and end of the curve (essentially leaving you with 4 straight pcs. along the sides and curved pcs. Glue the straight pieces first, then do the corners. You'll have to make relief cuts in the corners so you don't get pulls or wrinkles (how many depends on the material).
  • When you get to the edge of the headliner, you only need to leave enough to fold over about an inch.
This is what the material I was using looks like:


Once you work the fabric down, and its dry you need to cut the holes for the sun visors, lights, hooks, handles and consoles. DONT FORGET TO PUNCH THE HOLES FOR SUN VISOR CATCHES. (I discovered that one the hard way). To make things simple, the cuts are as follows:
Vanity Lights & Grab Handles: Just cut an X from the back making sure to go just up to the corner.
Sun Visor Mounts & Accessory Hooks: Cut a hole in the center leaving ~1/8" around the edges.
Consoles: Cut it flush with the edge.



Ready to go back in:


Once you have all the holes trimmed nicely its time to put the darn thing back in, and enjoy a cold one!
X5SND can you share with us the brand and type os suede headliner material that you obtained? Thanks
Reply With Quote
  #29
Old 09-18-2015, 09:36 AM
TiAgX5's Avatar
Member

Join Date: Oct 2010
Location: Coppell,TX
Posts: 3,475
TiAgX5 is on a distinguished road
I'm seeing some headliner fabric from foam separation on the sunroof slider.

Can that panel be removed without taking the entire roof liner out?
__________________
'03 X5 4.4 Sport, last of the M62s (8-03 build date)
I believe in deadication to craftmanship in a world of mediocrity!
Reply With Quote
  #30
Old 09-18-2015, 03:44 PM
Member

Join Date: Oct 2011
Location: NYC
Posts: 4,426
SlickGT1 is on a distinguished road
Quote:
Originally Posted by TiAgX5 View Post
I'm seeing some headliner fabric from foam separation on the sunroof slider.

Can that panel be removed without taking the entire roof liner out?
Mine came off completely on my pano roof sliding part. I fixed it on the spot with spray adhesive. Biggest bitch is I had some minor bleed through as stated above. Only in the corners. No one will really ever notice, except me, and it drives me nuts. Just don't spray too much at once.
__________________
2006 4.8is, Black on White.

"The older we grow the greater becomes our wonder at how much ignorance one can contain without bursting one's clothes." - Mark Twain

Unlock OBC post 5
