  #21
Old 10-19-2018, 01:37 PM
EODguy's Avatar
Member

Join Date: Jun 2018
Location: Saudi Arabia/Philippines/USA
Posts: 434
EODguy is on a distinguished road
rswapp, what year and model is your e53?

Sent from my SM-A730F using Tapatalk
__________________
"When the Team Chief said.... You're trapped in a hole with nothing but a goat and a slinky, what do you do? Stubby said, I'm not sure but it won't end well for the goat...." ~(Overheard) Last day, Phase 3, Q Course
Reply With Quote

Sponsored Links

  #22
Old 10-19-2018, 02:48 PM
Member

Join Date: Nov 2014
Location: SF Bay Area
Posts: 727
oldskewel is on a distinguished road
Quote:
Originally Posted by rswapp View Post
It just amuses me to see how many people don't know what or how a magnetic reed switch works. The Magnet operates the reed switch which is the coolant level sensor. It operates like a door alarm switch where you have a fixed magnet and a fixed switch. As the magnet gets into the proper proximity of the switch it either opens or closes the switch depending on if it's a NC or NO switch. Pretty easy circuit to understand. So it's not the magnet that is communication with the system but the magnet is operating the reed switch that then tells the system if the coolant is low or okay.
I don't think there is any doubt or misunderstanding by most people on here about any of that. Yes, reed switch, magnet, pretty straightforward. The mystery and unexplained behaviour comes when you consider the more intricate details as clearly and carefully laid out in post #16.

I've never had a problem with my coolant level sensor, but read this for interest in knowing how my car works, and solving problems. Tough when you know some things presented as facts are wrong, etc. But it really did seem weird ... until that post #16. After that, everything does make sense, and I feel I'll be able to carefully troubleshoot a problem if one ever occurs.

Have you done tests on your own system to confirm that post #16's system description it correct or not? I have not, but it does seem to be the explanation for all the (previously) confusing reports in just about every other post on this issue.
__________________
2001 X5 3.0i, 180k miles, AT, owned since 11/2014
Reply With Quote
  #23
Old 10-19-2018, 03:20 PM
Member

Join Date: Mar 2016
Location: Saskatchewan Canada
Posts: 844
80stech is on a distinguished road
Me 2, post #16 should be made more obviuosly available to reference somehow. I was wanting to re-activate my low coolant warning system, just haven't done it yet. Post #16, assuming it is accurate is very good information.
__________________
1988 325is (purchased new)
2004 X5 3.0 (new to me) 2005 X3 2.5 (new to wife)
Reply With Quote
  #24
Old 01-09-2019, 01:54 PM
Member

Join Date: Jan 2019
Location: NewEngland
Posts: 2
Bermslayer is on a distinguished road
I know this is an older post...

But did you ever resolve your mystery or dilemma?

PS great posts and images on this one 8-)

2006 BMW X5 E53 M54 3.0i
Reply With Quote
  #25
Old 01-09-2019, 02:04 PM
Member

Join Date: Mar 2016
Location: Saskatchewan Canada
Posts: 844
80stech is on a distinguished road
Turns out I don't have the low coolant light(bulb anyway) because I have the Low cluster. I think I might go down another path and add an an E30 expansion tank. There were too many problems with not only the sensor but the fact that the difference between overfilling the expansion tank and the low coolant level being triggered is only about a cup or two of coolant from what I can tell. Anyone with the high cluster, would that be about right?
__________________
1988 325is (purchased new)
2004 X5 3.0 (new to me) 2005 X3 2.5 (new to wife)
Reply With Quote
  #26
Old 01-09-2019, 02:17 PM
Overboost's Avatar
//Binary is in my DNA

Join Date: Apr 2006
Location: Huntersville, NC
Posts: 1,457
Overboost is on a distinguished road
Quote:
Originally Posted by 80stech View Post
Turns out I don't have the low coolant light(bulb anyway) because I have the Low cluster. I think I might go down another path and add an an E30 expansion tank. There were too many problems with not only the sensor but the fact that the difference between overfilling the expansion tank and the low coolant level being triggered is only about a cup or two of coolant from what I can tell. Anyone with the high cluster, would that be about right?
Mine would trigger with only a cup low. You could still see coolant when you looked down the tank but definitely lets you know with plenty of warning.
__________________
  • 2004 E53 X5 3.0 ZSP (4/04 build date) Jet Black exterior/Sand Beige interior
  • 2002 E46 325i ZPP (2/02 build date) Alpine White exterior/Hell Beige interior

Digital Competition Systems
The older I get... The faster I was...
No Fear


Reply With Quote
  #27
Old 01-09-2019, 03:04 PM
Member

Join Date: Jan 2019
Location: NewEngland
Posts: 2
Bermslayer is on a distinguished road
E30 expansion tank?

Quote:
Originally Posted by 80stech View Post
Turns out I don't have the low coolant light(bulb anyway) because I have the Low cluster. I think I might go down another path and add an an E30 expansion tank. There were too many problems with not only the sensor but the fact that the difference between overfilling the expansion tank and the low coolant level being triggered is only about a cup or two of coolant from what I can tell. Anyone with the high cluster, would that be about right?
Is the E30 Expansion an exact swap for E53? What do you mean by "Low Cluster" or "High Cluster"
(New to BMW here). Thanks
Reply With Quote
  #28
Old 01-09-2019, 03:26 PM
Member

Join Date: Mar 2016
Location: Saskatchewan Canada
Posts: 844
80stech is on a distinguished road
No, it's not a swap, I am going to add it in. There is a ton of info on both the expansion tank and the High and Low clusters in other threads if you want to get started on checking into those.
__________________
1988 325is (purchased new)
2004 X5 3.0 (new to me) 2005 X3 2.5 (new to wife)
Reply With Quote
  #29
Old 01-09-2019, 04:14 PM
Member

Join Date: Nov 2014
Location: SF Bay Area
Posts: 727
oldskewel is on a distinguished road
Quote:
Originally Posted by Bermslayer View Post
...What do you mean by "Low Cluster" or "High Cluster"
(New to BMW here). Thanks
Basically for a High Cluster (not sure of the official name, but that's what is called in this forum), there is an LCD orange pixel display at the bottom of the instrument panel where it can show words like "COOLANT LEVEL LOW" or "TRANS FAILSAFE PROG.".

Low Cluster E53's do not have that display, so it can't tell you complex stuff like that, and makes up for some of it with more warning lights (e.g., as was recently confirmed in another thread, the low clusters have a coolant high temp warning light, and the high clusters do not - and probably make up for it with a gong sound and written warning).

Going beyond the display limitations, since the low cluster E53's do not have any way to indicate low coolant level, they do not have a coolant level sensor or the wiring to plug in a sensor. Even if a replacement coolant expansion tank comes with a coolant level sensor, there is no easy way to use it on a Low-Cluster E53.
__________________
2001 X5 3.0i, 180k miles, AT, owned since 11/2014
Reply With Quote
