mavros44 · #1 03-10-2010, 02:51 PM

can you help me...?? i buy yesterday a used 10/ 2004 x3 2.0d with nav.i checked that i have a tcu 84.109129850-01. but i can not pair the phone.on the screen of the radio-nav i only have options like computer-sat nav-set and monitor off (if i remember right) .i can not find any option about telephone.what i have to do??

Brian-bmw · #2 03-10-2010, 03:28 PM

If the "Telephone" option is not displayed on the main navigation menu, then the TCU is either not connected or it has failed. Based on the date of manufacture, that TCU should have the Bluetooth feature, but I am not as familiar with the European TCU modules.

mavros44 · #3 03-10-2010, 03:37 PM

yes on the top of the tcu has the logo of the bluetouth and a 4 digit pk.it is like this one http://filer.case.edu/jxw115/BMW/BTO.../img_1131a.jpg

neiloakley · #4 03-11-2010, 05:16 AM

Check its plugged in firmly and that the fuse isn't blown. If the unit doeasn't have power, the car wont know its there.

big bob · #5 03-19-2010, 12:50 PM

Did anyone have probles getting a TCU into pairing mode? Some people in this thread report the need to plug in the eject box temporarily to get pairing to start.

big bob · #6 03-19-2010, 07:46 PM

Quote:

Originally Posted by KiwiJochen

I do not know of a way to initiate bluetooth pairing mode programmatically on the TCU-GSM, hence the BT Pairing button is disabled.

Quote:

Originally Posted by big bob

Did anyone have probles getting a TCU into pairing mode? Some people in this thread report the need to plug in the eject box temporarily to get pairing to start.

Maybe this extra step is required?

Quote:

Originally Posted by BMW tech buletin

PAIRING PROCEDURE E46/E83/E85/E53
1) Turn Key off and then to KL-R or KL-15. 1.
2)The vehicle is ready for pairing for the first 2 minutes of key on. 2.
3) If the R/T button on the MFL is pressed, "Activate Phone" appears on the MID or Board Monitor. For the E53 X5 the seatbelt needs to be plugged in and the R/T button pressed on the MFL and "Activate Phone"
appears in the Instrument Cluster.

Link

Jochen> What is the navcoder command for R/T and seatbelt-in and I can try this on my bench?!

KiwiJochen · #7 03-20-2010, 02:29 AM

Quote:

Originally Posted by big bob

What is the navcoder command for R/T and seatbelt-in and I can try this on my bench?!

Press the "R/T" button on the steering wheel emulator in NavCoder

big bob · #8 03-20-2010, 08:04 AM

Quote:

Originally Posted by KiwiJochen

Press the "R/T" button on the steering wheel emulator in NavCoder

I logged
20/03/2010 11:58:23.881: 50 04 68 3B A0 A7
20/03/2010 11:58:23.881: MFL --> RAD : Radio/Telephone control: Send/End_released

I think I need to try it in the car, if it ever comes back from the mechanic...

KiwiJochen · #9 03-20-2010, 08:51 AM

Quote:

Originally Posted by big bob

I logged
20/03/2010 11:58:23.881: 50 04 68 3B A0 A7
20/03/2010 11:58:23.881: MFL --> RAD : Radio/Telephone control: Send/End_released

I think I need to try it in the car, if it ever comes back from the mechanic...

R/T =
20/03/2010 1:50:33 p.m..282: 50 04 68 3B 02 05
20/03/2010 1:50:33 p.m..282: MFL --> RAD : Radio/Telephone control: R/T_pressed
20/03/2010 1:50:33 p.m..463: 50 04 68 3B 22 25
20/03/2010 1:50:33 p.m..463: MFL --> RAD : Radio/Telephone control: R/T_released

the sneezing man = Send/End =
20/03/2010 1:50:37 p.m..476: 50 04 C8 3B 80 27
20/03/2010 1:50:37 p.m..476: MFL --> TEL : Radio/Telephone control: Send/End_pressed
20/03/2010 1:50:37 p.m..563: 50 04 C8 3B A0 07
20/03/2010 1:50:37 p.m..563: MFL --> TEL : Radio/Telephone control: Send/End_released

Brian-bmw · #10 03-19-2010, 01:10 PM

It is possible that a European TCU uses the pairing button in gibbo_ireland's situation. Or, it is just as likely that gibbo_ireland had a ULF and not a TCU. I vote for the latter. Every BMW document I have read and everyone else's documented experience I have read states that the TCU goes into pairing mode every time you start the car.
