  #31
Old 03-04-2014, 01:23 AM
Member

Join Date: Feb 2013
Location: Columbia, MO
Posts: 35
tankowner is on a distinguished road
Quote:
Originally Posted by tankowner View Post
Yes, exactly, that is the issue here. If we go through the trouble of removing the whole knuckle, then we have access and can drive the ball joint out from the top with your tool of choice (BFH and drift, air chisel, rental ball joint press, etc.). But, for now, I am trying to remove the ball joint without removing the entire knuckle. As a matter of fact, I am off to do battle right now . . . I'll let you know how it goes.

By the way, the slide hammer (special tool) looks very interesting, I wonder how well it works. Thanks.
Well, I concede defeat for tonight. I was able to get the pipe wrench on, but couldn't get the ball joint to break free. Spent some time cutting into it with a wheel cutter, but it seemed like a losing cause. Tomorrow the knuckle comes off, which is fine I guess - I need new brake pads anyway, so I can get that done now, too.
__________________
_____________________________

2001 e53 X5 3.0i (10/2000 build date) - Beige exterior, Beige/Sand interior w/ light wood
Reply With Quote

Sponsored Links

  #32
Old 03-04-2014, 02:38 AM
MINIz guy's Avatar
Member

Join Date: Jul 2008
Location: Bear, DE
Posts: 1,264
MINIz guy is on a distinguished road
That sours up the whole operation. Does the front axle get in the way much or can you just drop the knuckle down and be fine? Or is the axle in the way and that is why the knuckle has to come off of it?

Sorry, I'm not familiar with the X5's suspension and driveline and cannot imagine it in my head.
__________________
Reply With Quote
  #33
Old 03-04-2014, 03:04 AM
rogerkiu's Avatar
Member

Join Date: Oct 2005
Location: Hong Kong
Posts: 1,062
rogerkiu is on a distinguished road
Quote:
Originally Posted by tankowner View Post
Yes, exactly, that is the issue here. If we go through the trouble of removing the whole knuckle, then we have access and can drive the ball joint out from the top with your tool of choice (BFH and drift, air chisel, rental ball joint press, etc.). But, for now, I am trying to remove the ball joint without removing the entire knuckle. As a matter of fact, I am off to do battle right now . . . I'll let you know how it goes.

By the way, the slide hammer (special tool) looks very interesting, I wonder how well it works. Thanks.
No idea how well it works, but it is from BMW TIS, which means BMW service center uses this special tool to remove the joint, so I believe it should works very well.
Attached Images

__________________
--2004 E53 X5 4.8is - ECE version; right hand drive; Located in Hong Kong; ext. black sapphire metallic; int. leather black; adaptive dynamic bi-xenon headlights; 16:9 onboard monitor w/o navigation; 20" genuine BMW Y-spoke 214 wheels with Bridgestone Dueler H/P Sport tires; Int. rear view mirror w/ compass.
Reply With Quote
  #34
Old 03-04-2014, 09:01 AM
Member

Join Date: Oct 2012
Location: Hampshire UK
Posts: 106
white lancer is on a distinguished road
Don't know what all the fuss is about. I did not even know there was a special tool for removing the ball joint. When I changed mine I just soaked the joint in WD40 for a few hours, removed the two bolts holding it in place and then beat it out using a 2lb lump hammer on the end of the control arm as close to the ball joint as possible whilst holding on to the other end of the control arm in my other hand. I replaced the control arm as well as the ball joint so it did not matter that I beat it to death. As far as I remember the ball joint came loose fairly easily, maybe 10 or 12 blows with the lump hammer?
__________________
E90 318i 2007 N46 2.0 Manual
E53 X5 2004 M54 3.0 Sport Auto
E83 X3 2004 M54 2.5 Auto
Reply With Quote
  #35
Old 03-04-2014, 09:26 AM
upallnight's Avatar
Member

Join Date: Aug 2012
Location: Cook County
Posts: 7,280
upallnight is on a distinguished road
Quote:
Originally Posted by white lancer View Post
Don't know what all the fuss is about. I did not even know there was a special tool for removing the ball joint. When I changed mine I just soaked the joint in WD40 for a few hours, removed the two bolts holding it in place and then beat it out using a 2lb lump hammer on the end of the control arm as close to the ball joint as possible whilst holding on to the other end of the control arm in my other hand. I replaced the control arm as well as the ball joint so it did not matter that I beat it to death. As far as I remember the ball joint came loose fairly easily, maybe 10 or 12 blows with the lump hammer?
He removed the control arm so he doesn't have anything to beat on.
__________________
2006 Infiniti G35
2001 BMW 3.0I E53 X5 Build date 08/2000 SOLD
Lotus Europa 1970 Destroyed by fire
Lotus Europa 1970 S2 Renault Powered
Lotus Type 52 1970 Twincam Webers Powered
PORSCHE 911 Targa 1982 The Garage Queen
Audi Avant donated to Kars for Kids
BMW 525IT Sold
Audi 4000CS Quattro Sold
Jensen Healey Lotus Powered Sold
Opel 1900 Sold
Triumph Spitfire 1971 Sold
Triumph Spitfire 1968 Sold
Plymouth "Cuda" 340 Six pack SOLD
Reply With Quote
  #36
Old 03-04-2014, 09:38 AM
Member

Join Date: Oct 2012
Location: Hampshire UK
Posts: 106
white lancer is on a distinguished road
aha - there in lies the problem....
__________________
E90 318i 2007 N46 2.0 Manual
E53 X5 2004 M54 3.0 Sport Auto
E83 X3 2004 M54 2.5 Auto
Reply With Quote
  #37
Old 03-04-2014, 10:20 AM
Member

Join Date: Feb 2013
Location: Columbia, MO
Posts: 35
tankowner is on a distinguished road
Quote:
Originally Posted by MINIz guy View Post
That sours up the whole operation. Does the front axle get in the way much or can you just drop the knuckle down and be fine? Or is the axle in the way and that is why the knuckle has to come off of it?

Sorry, I'm not familiar with the X5's suspension and driveline and cannot imagine it in my head.
Yes, the CV axle is right above the top of the ball joint, so if you want to beat it out, you need to at least remove the outer end of the CV axle from the knuckle.


Quote:
Originally Posted by white lancer View Post
Don't know what all the fuss is about. I did not even know there was a special tool for removing the ball joint. When I changed mine I just soaked the joint in WD40 for a few hours, removed the two bolts holding it in place and then beat it out using a 2lb lump hammer on the end of the control arm as close to the ball joint as possible whilst holding on to the other end of the control arm in my other hand. I replaced the control arm as well as the ball joint so it did not matter that I beat it to death. As far as I remember the ball joint came loose fairly easily, maybe 10 or 12 blows with the lump hammer?
I suspect there will be some variation here, with some ball joints coming out easier than others. My X5 is real close to 200,000 miles and these have never been changed. I wire brushed all around the top, sprayed liberally with PB Blaster, let it soak over night and I still can't get the thing to budge. (Yes, for the record, I did remove the two bolts holding it in.) I will happily hook up the control arm again and pound on it with a 10 lb sledge, but I don't think that is going to gain me anything.

Quote:
Originally Posted by rogerkiu View Post
No idea how well it works, but it is from BMW TIS, which means BMW service center uses this special tool to remove the joint, so I believe it should works very well.
I think it would be worth a shot and you could probably get the rental tool from one of the auto parts chain stores and then find the right threaded fitting to mate up to the ball joint. The only problem for me is that I am doing this on my garage floor with front jacked up and I don't know that I would have enough room get the slide hammer in there and use it effectively.
__________________
_____________________________

2001 e53 X5 3.0i (10/2000 build date) - Beige exterior, Beige/Sand interior w/ light wood
Reply With Quote
  #38
Old 03-04-2014, 11:17 AM
Member

Join Date: Oct 2012
Location: Hampshire UK
Posts: 106
white lancer is on a distinguished road
Quote:
Originally Posted by tankowner View Post
I suspect there will be some variation here, with some ball joints coming out easier than others. My X5 is real close to 200,000 miles and these have never been changed. I wire brushed all around the top, sprayed liberally with PB Blaster, let it soak over night and I still can't get the thing to budge. (Yes, for the record, I did remove the two bolts holding it in.) I will happily hook up the control arm again and pound on it with a 10 lb sledge, but I don't think that is going to gain me anything.
Seriously..... put the control arm back on loose and attack it with a 2lb hammer - I think you won't gain anything using a 10lb sledge - you wont get it in there for a start!

Have you tried a bit of heat?
__________________
E90 318i 2007 N46 2.0 Manual
E53 X5 2004 M54 3.0 Sport Auto
E83 X3 2004 M54 2.5 Auto
Reply With Quote
  #39
Old 03-04-2014, 11:51 AM
axgordon's Avatar
Member

Join Date: Feb 2010
Location: USA Maryland
Posts: 95
axgordon is on a distinguished road
I was in the same situation. Used MAP gas torch on the knuckle around ball joint. I heated for at least 5 minutes and then drove ball joint out with the air chisel. It didn't move without heat.


Sent from my iPhone using Tapatalk
__________________

2012 X5 x35i My new toy
2005 X5 4.4 Her's (Retrofitted Servotronic Steering Rack)
2003 X5 3.0 Mine (Retrofitted Servotronic Steering Rack and Heated Steering Wheel)
2001 M5 Son's car
2000 540i 6sp Sports pkg, supercharged. Son's car (Sold)
2001 530i (Sold)
1999 528i (Sold)
1975 2002 (Sold)
Reply With Quote
  #40
Old 03-04-2014, 12:10 PM
Member

Join Date: Dec 2010
Location: MN
Posts: 214
Junkycosmos is on a distinguished road
I was looking for the air rattler tool I mentioned in prior post. These go were two of the tips Indy mechanic had.

Save on Grey Pneumatic - CH117 at ToolTopia.com

and

Amazon.com: Lisle 54640 Pneumatic Tie Rod Rattler: Automotive

I believe he rattle mainly from the bottom. I can also confirm on the right side he did not remove the thrust arm from the ball joint prior but rather used it for leverage to pull down with while rattling. All of this was done with all other parts other still fully installed (well the tire was removed).

G Luck
__________________
2003 E39 530i
1992 MX5
2005 E53 x5 4.8is (sold)
1990 K75S (sold)
Reply With Quote
