  #41
Old 05-08-2011, 02:30 AM
Member

Join Date: Jun 2007
Location: New Zealand
Posts: 58
dlclarke is on a distinguished road
Quote:
Originally Posted by big bob View Post
I'm curious about why you need to change the VIN for INPA? Is there some feature that becomes enabled when the VINs match? I thought the VIN was only for reporting back to BMW in an E-Call.
Right now I wish I hadn't, but in researching INPA (actually, it might have been GT1) I remember reading that modules that weren't coded for VIN caused them to not show up with INPA and caused incompatibilities and errors throughout the vehicle. If they were blank (ie replacement parts from BMW), then that was fine, but to have the wrong VIN in them caused problems - in terms of reading them and their logs, and clearing faults. It was in relation to lighting Control Modules but also referenced the entertainment items as well.

Live and learn I guess, I figure since the smoke hasn't escaped out of it yet, we are still in the hunt to get it working

If at the end of the day it doesn't work, its off to the range and unleash the .50 cal on its ar$e
Reply With Quote

Sponsored Links

  #42
Old 05-08-2011, 02:59 AM
Member

Join Date: Jun 2006
Location: UK
Posts: 698
big bob is on a distinguished road
It's weird. I once sold a 2004/2005 ish TCU I couldn't get to pair (I was powering it up outside the car) and the new owner had no problems at all. The car had BT from the factory.

So I had a google and found a post from 2004.

Now I've never heard of a retrofit needing coding, but I suppose it might be possible.

Last edited by big bob; 05-08-2011 at 03:11 AM.
Reply With Quote
  #43
Old 05-08-2011, 05:12 AM
Member

Join Date: Jun 2007
Location: New Zealand
Posts: 58
dlclarke is on a distinguished road
Some progress, I have the name back! The TCU had gone into powersave mode (lets assume that was me with INPA and very basic German). So whilst not pairing still, we have Jochen (I will have to buy him a bathtub full of beer) onto its case.



Last edited by dlclarke; 05-08-2011 at 05:17 AM.
Reply With Quote
  #44
Old 05-08-2011, 05:33 AM
Member

Join Date: Jun 2006
Location: UK
Posts: 698
big bob is on a distinguished road
I wonder if somone has a Country Coding response for a car that was fitted with BT from teh factory? We could send that to a TCU and see if the BT starts to work.

Another 'interesting' find.
Quote:
A: If not equipped with BT eject box:
Turn key from ignition 0 to ignition 1 or higher.

1. B: If equipped with BT eject box: Press & hold the button above the storage compartment, then after about 3 seconds, turn the ignition
key to position 1 and release the button after approximately 3 seconds.
“BLUETOOTH PAIRING” appears on the display or monitor.
During the pairing process, depending on equipment the indicator lights on the on-board computer or on the multi-information display flash.

If no paired mobile phone is detected inside the vehicle, the message “PHONE CONNECTED?” or “ACTIVATE PHONE” appears on the display or monitor
Reply With Quote
  #45
Old 05-08-2011, 06:14 AM
Member

Join Date: Jun 2007
Location: New Zealand
Posts: 58
dlclarke is on a distinguished road
Interesting idea.

The "Bluetooth Pairing" message seems to be a ULF thing, as does the eject box.

If no paired mobile phone is detected inside the vehicle, the message “PHONE CONNECTED?” or “ACTIVATE PHONE” appears on the display or monitor

I am certainly left with the "ACTIVATE PHONE" at the end of the 2 mins of "Searching...".

I get the feeling that these are locked into a 1:1 pairing with a car installed phone and need to be in some way coded to be free to Pair with any phone, not just a dealer supplied, and car installed one. Or I could have it completely wrong
Reply With Quote
  #46
Old 05-08-2011, 07:18 AM
Member

Join Date: Jun 2006
Location: UK
Posts: 698
big bob is on a distinguished road
Quote:
Originally Posted by dlclarke View Post
Interesting idea.

The "Bluetooth Pairing" message seems to be a ULF thing, as does the eject box.

If no paired mobile phone is detected inside the vehicle, the message “PHONE CONNECTED?” or “ACTIVATE PHONE” appears on the display or monitor

I am certainly left with the "ACTIVATE PHONE" at the end of the 2 mins of "Searching...".

I get the feeling that these are locked into a 1:1 pairing with a car installed phone and need to be in some way coded to be free to Pair with any phone, not just a dealer supplied, and car installed one. Or I could have it completely wrong
I think you are wrong, because when you search for the Part Number of your TCU, it comes up for SA633, bluetooth. WDCT really was dropped in about 2004.
Quote:
Originally Posted by big bob View Post
Single parts SA 633, trunk 01 ... — '06, November Telematics Control Unit 84 10 9 129 850

That's Bluetooth. WDCT was canned in TCUs after late 2004.
It may well be the car needs to be coded as supporting bluetooth.
Reply With Quote
  #47
Old 05-09-2011, 04:21 AM
Member

Join Date: Jun 2007
Location: New Zealand
Posts: 58
dlclarke is on a distinguished road
I am starting to come around to the fact that the car needs coding too. I have run NCS Expert over it, and it assumes its still got the Bit II module in it, and faults out when I try and access it. NCS lists 4 different TCUs and 4 ULFs but none of them find the unit in my car. I guess I need to understand which module holds the coding and turn off BIT-II and then find out how to add a TCU... Any suggestions??? I have the instructions for tuning stuff off, but not adding a unit.
Reply With Quote
  #48
Old 05-09-2011, 05:04 AM
Member

Join Date: Jun 2006
Location: UK
Posts: 698
big bob is on a distinguished road
I'm sorry I don't know how to add and remove options without using SSS, which I have never attempted to get working. NCS can do it if you change the vehicle order but it's not something I know the codes for. You need to run SSS in a virtual machine and create a LAN-USB software bridge, so it's less simple than INPA to get going.
Reply With Quote
  #49
Old 05-09-2011, 05:29 AM
Member

Join Date: Jun 2007
Location: New Zealand
Posts: 58
dlclarke is on a distinguished road
Quote:
Originally Posted by big bob View Post
I'm sorry I don't know how to add and remove options without using SSS, which I have never attempted to get working. NCS can do it if you change the vehicle order but it's not something I know the codes for. You need to run SSS in a virtual machine and create a LAN-USB software bridge, so it's less simple than INPA to get going.
Its just software and a computer, I will get right onto it. I have an IBM X31 sitting here for just that purpose, so off we go.
Reply With Quote
  #50
Old 05-09-2011, 05:44 AM
Member

Join Date: Jun 2006
Location: UK
Posts: 698
big bob is on a distinguished road
I have a CD that someone made for me [CCJF1] that supposedly has all the things one needs on it (all versions and LAN bridges). I will try to get you a copy after work.
Reply With Quote
